Decowell EtherNet IP Multifunctional Modules , Communication IO Module DC24V IP40

Name: Decowell EtherNet IP Multifunctional Modules Communication IO Module DC24V IP40
Brand: DECOWELL
Price: 1 USD

Brand Name : DECOWELL

Model Number : EI2-S2

Certification : ISO: 9001, CE

Place of Origin : China nanjing

MOQ : 1 pieces

Price : USD $82.85

Payment Terms : Western Union, MoneyGram, T/T

Supply Ability : 1000000pieces/Year

Delivery Time : 5-8 workdays

Packaging Details : Carton packing，LxW90x100x45.4mm.

Model NO. : EI2-S2

Customized : Customized

Material : ABS+PC

OEM : Yes

ODM : Yes

Bus Protocol : Ethernet/IP

Class of Protection : IP40

Transport Package : Cartons

Specification : 162mmX61mmX35mm

Trademark : DECOWELL

Origin : Nanjing

HS Code : 8538900000

Package Size : 19.90cm * 8.50cm * 4.20cm

Package Gross Weight : 0.176kg

Function : Automatic Control

Condition : New

Customization : Available | Customized Request

Shipping Cost : about shipping cost and estimated delivery time.

Currency : US$82.85

Return&refunds : You can apply for a refund up to 30 days after receipt of the products.

Contact Now

Decowell RS Series Integrated I/O EI2-S2 Communication Module for Customization Needs

Decowell RS series integrated I/O EI2-S2 Communication Module.
RS series integrated l/O modules support a variety of industrial fieldbusprotocols, such as EtherCAT, PROFINET, EtherNet/lP, DeviceNet, etc. The I/O modules support a maximum of 32 channels of digital inputs/digi-tal outputs, and users can choose different I/O module componentsaccording to the actual needs, with single-slot and dual-slot chassisavailable.The RS series bus protocols are respectively

Each bus protocol of RS series supports 16DI NPN, 16DI PNP, 16DO NPN, 16DO PNP, 8DI8DO NPN, 8DI8DO PNP, 8DO relay respectively.

Bus protocol	EtherNet/IP
Communication distance	100m(distance from station to station)
Bus communication rate	100Mbps
topology	Depends on EtherNet/IP master specifications
Device name	Software distribution
System power input	DC24V(18-30V)
The system power supply provides current	2A
IO power input	DC24V(18-30V)
The IO power supply provides current	10A
Overcurrent protection	YES
Overvoltage protection	NO
Anti-reverse connection protection	YES
System side electrical isolation	YES
Operating ambient temperature	-10°C-55°C
Working ambient humidity	10%-95% no condensation
Height of working environment	<2000m
Use ambient air	non-corrosive
EMC level	Zone A
Class of protection	IP40

Decowell EtherNet IP Multifunctional Modules , Communication IO Module DC24V IP40
